Width: 20.50"
Height: 12.50"
Depth: 16"
Net size, after displacements, 1.26 Cubes
Width: 1.50"
Height: 11"
Depth: 29.50"
Turning frequency based off actual port: 32.75Hz
Top Bottom: 20.50" x 16" (2 Pieces)
Front: 11" x 17.50" (1 Piece)
Back: 11" x 19" (1 Piece)
Sides: 11" x16" (2 Pieces)
Port Wall #1: 11" x 13" (1 Piece)
Port Wall #2: 11" x 14" (1 Piece)
Material Thickness: .75"
Width: 28"
Height: 14"
Depth: 18"
Net size, after displacements, 2.25 Cubes
Width: 2.75"
Depth: 31.50"
Tuning frequency based off actual port: 33.5Hz
Top & Bottom: 28" x 18" (2 pieces)
Front: 24.5" x 12.5" (1 piece)
Back: 26.5" x 12.5" (1 piece)
Sides: 17.25" x 12.5" (2 pieces)
Port Wall #1: 13.75" x 12.5" (1 piece)
Port Wall #2: 13.75" x 12.5" (1 piece)
You can change the wiring configuration of your speakers (Series, Parallel and Series / Parallel) to match the impedance loads that maximizes the power output of you amplifier. Wiring the same woofer or multiple woofers in these three different wiring configurations will result in different impedance loads.
Series: Is the method of wiring of alternate positive with negative terminals (string method) (Illustration below)
Parallel:Is the method of wiring where you wire match 2 speaker terminals with positive to positive terminal and negative to negative. (Illustration below)
Series/Parallel: This configuration is a combination of both series and parallel. We recommend series for the terminal and parallel for the leads to amp. (Illustration below).
