Product Type
Magnet Dimension
Magnet Weight
Magnet Efficiency
Spider Material
Lead Wire Dimension
Lead Wire Materials
Voice Coil Wire Material
Voice Coil Former Material
Voice Coil Diameter
Voice Coil Winding Height
Top plate height
Linear Excursion (one-way)
Effective Xmax
Subwoofer Chassis
2*190*25mm
2x95OZ
Y35
Black Nomex
84GA
Flat Tinsel Wove
Round Copper
Black Aluminum
63.5mm/2.5"
50mm/1.97"
20mm/0.79"
15mm/0.59"
45mm/1.77"
You can change the wiring configuration of your speakers (Series, Parallel and Series / Parallel) to match the impedance loads that maximizes the power output of you amplifier. Wiring the same woofer or multiple woofers in these three different wiring configurations will result in different impedance loads.
Series: Is the method of wiring of alternate positive with negative terminals (string method) (Illustration below)
Parallel:Is the method of wiring where you wire match 2 speaker terminals with positive to positive terminal and negative to negative. (Illustration below)
Series/Parallel: This configuration is a combination of both series and parallel. We recommend series for the terminal and parallel for the leads to amp. (Illustration below).
